TH-330B Technical Data
|
No.
|
description
|
details
|
|
1
|
Cutting capacity
|
Single
|
Max. ø330 mm
nW330×H330 mm
|
|
Min. ø20 mm
nW20×H8 mm
|
|
bunch
|
Max. nW300×H160 mm
|
|
Min. nW160×H20 mm
|
|
2
|
saw blade size
|
4115X34 X1.1 mm
|
|
3
|
saw speed
|
15-100 m/min（inverter）
|
|
4
|
feeding speed
|
stepless mm/min
|
|
5
|
main power
|
4 kw
|
|
6
|
Workpiece clamping way
|
Hydraulic horizontal clamp
|
|
7
|
Blade tension way
|
Hydraulic
|
|
8
|
Chip remove way
|
auto
|
|
9
|
hydraulic power
|
0.75 kw
|
|
10
|
coolant power
|
0.06 kw
|
|
11
|
Feeding way
|
Hydraulic automatic feed
|
|
12
|
Repeat Feeding accuracy
|
±0.15mm
|
|
13
|
Cutting perpendicularity
|
0.4/100 mm
|
|
14
|
Water tank volume
|
90L
|
|
15
|
Hydraulic tank volume
|
55L
|
|
16
|
working table capacity
|
1.5 T
|
|
17
|
Machine control voltage
|
24V DC
|
|
18
|
Supply voltage
|
380V 50Hz
|
|
19
|
feeding distance
|
0-500 mm
|
|
20
|
attached frame size
|
600 mm x 2PCS
|
|
21
|
machine size
|
2180×2190×1400mm
|
Machine picture:
Product name:High speed Intelligent CNC band saw TH-330B
Publish time:2025-11-3 0:00:00
|
